SIEG CNC Machining Center
SIEG CNC Machining Center
SIEG CNC Machining Center
SIEG CNC Machining Center
SIEG CNC Machining Center
SIEG CNC Machining Center
SIEG CNC Machining Center
SIEG CNC Machining Center

SIEG CNC Machining Center

SKU:
Price
$64,250.00
Model:
iKX9-SIEMENS 808DA
In stock and ready for shipping

Product Informations:

Pricing Note:
All prices shown are for general guidance only. Final pricing is POA (Price on Application) and varies depending on:

  • Control system selection (Fanuc, Siemens, GSK, etc.)
  • Equipment configuration and options
  • Custom requirements

For an accurate quote tailored to your needs, please contact us.

Specifications:

Model

Model

iKX9

iKX11

Worktable

Size

800x400mm

1000x500mm

T-Slot

16mm x3

18mm x3

Max. load

400kg

520kg

Travel

X travel

650mm

850mm

Y travel

420mm

500mm

Z travel

500mm

500mm

Spindle nose to table

100-600mm

100-600mm

Spindle center to column

600mm

590mm

Spindle

Spindle Taper

BT40

BT40

Spindle speed

8000rpm

12000rpm

Spindle Power

5.5kw

7.5 / 11kw

Axis

Max. X/Y/Z Speed

24m/min

36m/min

Max. X/Y/Z feeding speed

10m/min

10m/min

X/Y Motor

1.5KW

2.2KW

Z Motor

2KW

2.2KW

Tool Magazine

Tool number

16

24

Max tool length

250mm

300mm

Max tool weight

8kg

8kg

Accuracy

Positioning accuracy

0.008mm

0.006mm

Repeatability

0.006mm

0.005mm

Others

Weight

3000kg

4000kg

Overall dimension(mm)

2300x1900x2200

2620x2630x2500

Packing size (mm)

2500x2100x2400

2820x2820x2650

CNC Simulator Available for both model (Optional)
